| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4 mm @ F1.6, viewing angle: |
| 79° (Horizontal), 42° (Vertical), 92°(Diagonal) |
| PT Angle |
Pan: 353° , Tilt: 133° |
| Minimum Illumination |
0.1 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
WDR 80dB |
| BLC |
Supports |
| Night Vision |
10 m |
| Video & Audio |
| Max. Resolution |
2560 × 1440 |
| Frame Rate |
Max.25fps; Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| Video Bit Rate |
Ultra-HD; HD; Standard. Adaptive bit rate. |
| Audio Bit Rate |
Self-Adaptive |
| Max. Bitrate |
4Mbps |
| Network |
| Wi-Fi Standard |
IEEE802.11a, 802.11b, 802.11g, 802.11n, 802.11ac |
| Frequency Range |
2.4G:2400~2483.5MHz; 5G: |
| 5170~5250MHz,5735 - 5835MHz |
| Channel Bandwidth |
Support 40MHz |
| Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate |
11b 11Mbps, 11g 54Mbps, 11n HT20 MCS7, 11n HT40 |
| MCS7, 11a 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7 |
| Wi-Fi Pairing |
AP pairing |
| Protocol |
EZVIZ cloud proprietary protocol |
| Interface Protocol |
EZVIZ cloud proprietary protocol |
| Wired Network |
RJ45 × 1(10M/100M Adaptive Ethernet Port) |
| Storage |
| Local Storage |
MicroSD card slot (Max. 256 GB) |
| Cloud Storage |
EZVIZ Cloud Storage |
| Function |
| Smart Alarm |
AI-Powered Human Shape Detection / Pet Detection / |
| Waving-Hand Detection / Voice Activity Detection |
| Customized Alert Area |
Supports |
| Two-Way Talk |
Supports (Dual-Mic) |
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, |
| Password Protection, Watermark |
| General |
| Operating Conditions |
-10°C to 45°C (14°F to 113 °F), |
| Humidity 95% or less ( non-condensing) |
| Product Dimensions |
100 × 100 × 96.5 mm(3.93 × 3.93 × 3.80 inch) |
| Power Supply |
DC 5V/2A |
| Power Consumption |
Max. 8W |
| Packaging Dimensions |
116 × 116 × 164 mm (4.57 × 4.57 × 6.46 inch) |
| Weight (With Package) |
641 g (22.61 oz) |
| Net Weight |
325 g (11.46 oz) |
